| F - expands and contracts long greatly |
| |
| Model |
Expansion quantity
Lg
mm |
Length |
Rotor inertia I kg.m2 |
Weight G kg |
| Lmin |
Lmin |
Growth
100mm |
Lmin |
Growth
100mm |
| SWP160F |
150 |
770 |
0.14 |
0.0059 |
51 |
2.1 |
| SWP180F |
170 |
830 |
0.23 |
0.0072 |
64 |
2.3 |
| SWP200F |
190 |
950 |
0.40 |
0.0114 |
88 |
3.4 |
| SWP225F |
210 |
1070 |
0.66 |
0.0290 |
120 |
6.6 |
| SWP250F |
220 |
1110 |
1.06 |
0.0407 |
158 |
7.2 |
| SWP285F |
240 |
1270 |
2.24 |
0.0702 |
255 |
9.4 |
| SWP315F |
270 |
1410 |
3.99 |
0.1144 |
344 |
12.0 |
| SWP350F |
290 |
1540 |
6.90 |
0.1663 |
460 |
13.6 |
| SWP390F |
315 |
1680 |
11.90 |
0.2695 |
600 |
18.0 |
| SWP435F |
355 |
1880 |
22.41 |
0.3645 |
985 |
20.0 |
| SWP480F |
350 |
2080 |
39.09 |
0.7028 |
1356 |
28.0 |
| SWP550F |
360 |
2230 |
62.12 |
1.1842 |
1785 |
35.7 |
| SWP600F |
370 |
2800 |
100.48 |
1.7159 |
2403 |
4.05 |
| SWP640F |
380 |
2020 |
168.28 |
2.0380 |
3207 |
48.3 |
